IKW15N120BH6XKSA1

Product Details

Payment & Shipping Terms

Description: IGBT 1200 V 15A TO247-3-46

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Test Condition ::	600V, 15A, 22 Ohm, 15V	Product Category ::	IGBT Modules
Current - Collector Pulsed (Icm) ::	60A	Voltage - Collector Emitter Breakdown (Max) ::	1200V
Switching Energy ::	700µJ (on), 550µJ (off)	@ Qty ::	0
Mounting Type ::	Through Hole	Manufacturer ::	Infineon Technologies
Minimum Quantity ::	1	Factory Stock ::	0
Operating Temperature ::	-40°C ~ 175°C (TJ)	IGBT Type ::	Trench Field Stop
Reverse Recovery Time (trr) ::	340ns	Supplier Device Package ::	PG-TO247-3
Part Status ::	Active	Packaging ::	Tube
Gate Charge ::	92nC	Td (on/off) @ 25°C ::	18ns/240ns
Input Type ::	Standard	Package / Case ::	TO-247-3
Current - Collector (Ic) (Max) ::	30A	Power - Max ::	200W
Vce(on) (Max) @ Vge, Ic ::	2.3V @ 15V, 15A	Series ::	TrenchStop™

Test Condition ::	600V, 15A, 22 Ohm, 15V
Product Category ::	IGBT Modules
Current - Collector Pulsed (Icm) ::	60A
Voltage - Collector Emitter Breakdown (Max) ::	1200V
Switching Energy ::	700µJ (on), 550µJ (off)
@ Qty ::	0
Mounting Type ::	Through Hole
Manufacturer ::	Infineon Technologies
Minimum Quantity ::	1
Factory Stock ::	0
Operating Temperature ::	-40°C ~ 175°C (TJ)
IGBT Type ::	Trench Field Stop
Reverse Recovery Time (trr) ::	340ns
Supplier Device Package ::	PG-TO247-3
Part Status ::	Active
Packaging ::	Tube
Gate Charge ::	92nC
Td (on/off) @ 25°C ::	18ns/240ns
Input Type ::	Standard
Package / Case ::	TO-247-3
Current - Collector (Ic) (Max) ::	30A
Power - Max ::	200W
Vce(on) (Max) @ Vge, Ic ::	2.3V @ 15V, 15A
Series ::	TrenchStop™

Description

IKW15N120BH6XKSA1

The IKW15N120BH6XKSA1,from Infineon Technologies,is IGBT Modules.what we offer have competitive price in the global market,which are in original and new parts.If you would like to know more about the products or apply a lower price, please contact us through the “online chat” or send a quote to us!
