Description: 40A 650V TRENCHSTOP5 MEDIUM SPEE
Test Condition :: |
400V, 40A, 10 Ohm, 15V |
Product Category :: |
IGBT Modules |
Current - Collector Pulsed (Icm) :: |
160A |
Voltage - Collector Emitter Breakdown (Max) :: |
650V |
Switching Energy :: |
860µJ (on), 400µJ (off) |
@ Qty :: |
0 |
Mounting Type :: |
Surface Mount |
Manufacturer :: |
Infineon Technologies |
Minimum Quantity :: |
1000 |
Factory Stock :: |
0 |
Operating Temperature :: |
-40°C ~ 175°C (TJ) |
IGBT Type :: |
Trench Field Stop |
Reverse Recovery Time (trr) :: |
73ns |
Supplier Device Package :: |
PG-TO263-3 |
Part Status :: |
Active |
Packaging :: |
Tape & Reel (TR) |
Gate Charge :: |
95nC |
Td (on/off) @ 25°C :: |
19ns/130ns |
Input Type :: |
Standard |
Package / Case :: |
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
Current - Collector (Ic) (Max) :: |
79A |
Power - Max :: |
230W |
Vce(on) (Max) @ Vge, Ic :: |
1.74V @ 15V, 40A |
Series :: |
TrenchStop™ 5 |
Test Condition :: |
400V, 40A, 10 Ohm, 15V |
Product Category :: |
IGBT Modules |
Current - Collector Pulsed (Icm) :: |
160A |
Voltage - Collector Emitter Breakdown (Max) :: |
650V |
Switching Energy :: |
860µJ (on), 400µJ (off) |
@ Qty :: |
0 |
Mounting Type :: |
Surface Mount |
Manufacturer :: |
Infineon Technologies |
Minimum Quantity :: |
1000 |
Factory Stock :: |
0 |
Operating Temperature :: |
-40°C ~ 175°C (TJ) |
IGBT Type :: |
Trench Field Stop |
Reverse Recovery Time (trr) :: |
73ns |
Supplier Device Package :: |
PG-TO263-3 |
Part Status :: |
Active |
Packaging :: |
Tape & Reel (TR) |
Gate Charge :: |
95nC |
Td (on/off) @ 25°C :: |
19ns/130ns |
Input Type :: |
Standard |
Package / Case :: |
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
Current - Collector (Ic) (Max) :: |
79A |
Power - Max :: |
230W |
Vce(on) (Max) @ Vge, Ic :: |
1.74V @ 15V, 40A |
Series :: |
TrenchStop™ 5 |
