IRG4PSH71UPBF

Product Details

Payment & Shipping Terms

Description: IGBT 1200V 99A 350W SUPER247

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Test Condition ::	960V, 70A, 5 Ohm, 15V	Product Category ::	IGBT Modules
Current - Collector Pulsed (Icm) ::	200A	Voltage - Collector Emitter Breakdown (Max) ::	1200V
Switching Energy ::	4.77mJ (on), 9.54mJ (off)	@ Qty ::	0
Mounting Type ::	Through Hole	Manufacturer ::	Infineon Technologies
Minimum Quantity ::	50	Factory Stock ::	0
Operating Temperature ::	-55°C ~ 150°C (TJ)	IGBT Type ::	-
Reverse Recovery Time (trr) ::	-	Supplier Device Package ::	SUPER-247 (TO-274AA)
Part Status ::	Obsolete	Packaging ::	Bulk
Gate Charge ::	370nC	Td (on/off) @ 25°C ::	51ns/280ns
Input Type ::	Standard	Package / Case ::	TO-274AA
Current - Collector (Ic) (Max) ::	99A	Power - Max ::	350W
Vce(on) (Max) @ Vge, Ic ::	2.7V @ 15V, 70A	Series ::	-

Test Condition ::	960V, 70A, 5 Ohm, 15V
Product Category ::	IGBT Modules
Current - Collector Pulsed (Icm) ::	200A
Voltage - Collector Emitter Breakdown (Max) ::	1200V
Switching Energy ::	4.77mJ (on), 9.54mJ (off)
@ Qty ::	0
Mounting Type ::	Through Hole
Manufacturer ::	Infineon Technologies
Minimum Quantity ::	50
Factory Stock ::	0
Operating Temperature ::	-55°C ~ 150°C (TJ)
IGBT Type ::	-
Reverse Recovery Time (trr) ::	-
Supplier Device Package ::	SUPER-247 (TO-274AA)
Part Status ::	Obsolete
Packaging ::	Bulk
Gate Charge ::	370nC
Td (on/off) @ 25°C ::	51ns/280ns
Input Type ::	Standard
Package / Case ::	TO-274AA
Current - Collector (Ic) (Max) ::	99A
Power - Max ::	350W
Vce(on) (Max) @ Vge, Ic ::	2.7V @ 15V, 70A
Series ::	-

Description

IRG4PSH71UPBF

The IRG4PSH71UPBF,from Infineon Technologies,is IGBT Modules.what we offer have competitive price in the global market,which are in original and new parts.If you would like to know more about the products or apply a lower price, please contact us through the “online chat” or send a quote to us!
