Description: IGBT 650V 74A 255W PG-TO247-3
Test Condition :: |
400V, 20A, 15 Ohm, 15V |
Product Category :: |
IGBT Modules |
Current - Collector Pulsed (Icm) :: |
120A |
Voltage - Collector Emitter Breakdown (Max) :: |
650V |
Switching Energy :: |
350µJ (on), 100µJ (off) |
@ Qty :: |
0 |
Mounting Type :: |
Through Hole |
Manufacturer :: |
Infineon Technologies |
Minimum Quantity :: |
240 |
Factory Stock :: |
0 |
Operating Temperature :: |
-40°C ~ 175°C (TJ) |
IGBT Type :: |
Trench |
Reverse Recovery Time (trr) :: |
73ns |
Supplier Device Package :: |
PG-TO247-3 |
Part Status :: |
Not For New Designs |
Packaging :: |
Tube |
Gate Charge :: |
95nC |
Td (on/off) @ 25°C :: |
19ns/165ns |
Input Type :: |
Standard |
Package / Case :: |
TO-247-3 |
Current - Collector (Ic) (Max) :: |
74A |
Power - Max :: |
250W |
Vce(on) (Max) @ Vge, Ic :: |
2.1V @ 15V, 40A |
Series :: |
Automotive, AEC-Q101, TrenchStop™ |
